DL1036 1/3 HP 1075 3 SPD 115V 48FR MTR

This single-phase 1/3 horsepower fan and blower motor with a permanent split capacitor operates at 115V/5.4A/60Hz. It has a 9-1/2 inches length, a 5-3/5 inches diameter, a 4-1/2 inches length x 1/2 inch diameter shaft with flat, a maximum operating temperature of 104 degrees Fahrenheit, a 48Y-frame size, a capacitance rating of 7.5 MFD and an open enclosure. The 3-speed motor rotates reversibly at 1075 RPM and weighs 13 lb. It is UL-listed and features 26 inches leads, open-air over, ball bearing, thermal protection, Class B Insulation/40°C ambient and extended studs shaft end/resilient ring mounting/belly band mount.
