PS1X3K L.P CONTROL CAP TUBE

99024 PS1X3K Single Pressostat Pressure Control, Polycarbonate Cover, Steel Frame, 24/10/144A, 240 VAC, 24 VDC, -0.5 to 7 bar, 86mm L x 44mm W x 75mm H
Manufacturer: Emerson
$0.00
Single Pressostat Pressure Control, 86mm Length, 44mm Width, 75mm Height, Material: Polycarbonate Cover, Steel Frame, AMP: 24/10/144A, 240 VAC, 24 VDC Volts, Maximum Temperature: -50 to 70C, Pressure - Maximum: -0.5 to 7 bar, Pressure Connection: 1m Capillary with 7/16-20 UNF Flare Nut and Schrader Valve Opener, Reset Type: Automatic, Size: 15 in., Contact Type: (1) SPDT
Products specifications
products.specs.attributename products.specs.attributevalue
Length 86mm
Width 44mm
Height 75mm
Material Polycarbonate Cover, Steel Frame
AMP 24/10/144A
Maximum Temperature -50 to 70C
Pressure - Maximum -0.5 to 7 bar
Pressure Connection 1m Capillary with 7/16-20 UNF Flare Nut and Schrader Valve Opener
Size 15 in.
Volts 240 VAC, 24 VDC
