AQUV0409500TK

Aquamine V0409500TK Ductile Iron Lever Handle Standard Butterfly Valve, 4 in., Grooved

$0.00

Qty:

Aquamine Standard Butterfly Valve, 2950 Series, 12 in. Length, 7 in. Width, 10.15 in. Height, Ductile Iron, End Connection 1: Grooved, Pressure - Maximum: 250 psi, End Connection 2: Grooved, Specifications - ASTM: ASTM A-536 Grade 65-45-12, Valve Operator: Lever Handle, Valve Size: 4 in., Dimension: 4-1/2 in. Actual Size, Ductile Iron Valve Disc, Maximum Temperature: 73F, Recommended Valve Application: Water, 505 (Full Open) Flow Co-Efficient (Cv), Valve Body Style: Grooved

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	12 in.
Width	7 in.
Height	10.15 in.
Material	Ductile Iron
Dimension	4-1/2 in. Actual Size
End Connection 1	Grooved
End Connection 2	Grooved
Flow Co-Efficient (Cv)	505 (Full Open)
Maximum Temperature	73F
Pressure - Maximum	250 psi
Recommended Valve Application	Water
Specifications - ASTM	ASTM A-536 Grade 65-45-12
Valve Body Style	Grooved
Valve Disc Material	Ductile Iron
Valve Operator	Lever Handle
Valve Size	4 in.
