110223-308 ASTRO 250SS 3 SPEED CIRC

Armstrong 250SS Stainless Steel 3-Speed Astro 2 Circulating Pump 115 VAC at 60Hz 1 PH 1/2 hp

Manufacturer: S.A. Armstrong

$0.00

Qty:

Circulating Pump, Astro 2 Series, Model: 250SS, 6 in. Length, 6.38 in. Height, Stainless Steel, AMP: 0.65A (Speed 1), 0.79A (Speed 2), 0.98A (Speed 3), End Connection 1: Flanged, End Connection 2: Flanged, Fitting Size 1: 3/4, 1, 1-1/4, 1-1/2 in., Fitting Size 2: 3/4, 1, 1-1/4, 1-1/2 in., 0 - 64 gpm US Flow Rate, Horsepower: 1/2 hp, PA66 Noryl Impeller, Lead Law Compliant: Yes, 0 - 42 ft. Maximum Feet of Head, 110C Maximum - Temperature, Phase: 1 PH, Hardwired Power Source, Pressure - Maximum: 150 psi, ODP Pump Motor Type, In-Line Pump Mounting, CSA C22.2 Specifications - CSA Certified, Specifications - NSF: NSF 372, Specifications - NSF Certified: Yes, Specifications - UL Listed: Yes, 115 VAC VAC at 60 Hz, 3 Number of Speeds, 117W Power Rating, Ceramic Shaft Material, Ceramic Bearing Material, 40C Ambient Temperature Environmental Conditions

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	6 in.
Height	6.38 po
Material	Stainless Steel
AMP	0.65A (Speed 1), 0.79A (Speed 2), 0.98A (Speed 3)
Bearing Material	Ceramic
End Connection 1	Flanged
End Connection 2	Flanged
Environmental Conditions	40C Ambient Temperature
Fitting Size 1	3/4, 1, 1-1/4, 1-1/2 in.
Fitting Size 2	3/4, 1, 1-1/4, 1-1/2 in.
Horsepower	1/2 hp
Impeller	PA66 Noryl
Lead Law Compliant	Yes
Maximum Feet of Head	0 - 42 ft.
Maximum Temperature	110C
Phase	1 PH
Power Rating	117W
Power Source	Hardwired
Pressure - Maximum	150 psi
Pump Motor Type	ODP
Pump Mounting	In-Line
Shaft Material	Ceramic
Specifications - CSA Certified	CSA C22.2
Specifications - NSF	NSF 372
Specifications - NSF Certified	Yes
Specifications - UL Listed	Yes
VAC at 60 Hz	115 VAC
