BELLF24SR

Belimo LF24-SR Spring Return Damper Actuator, 4 - 20 mA, 24 VAC/VDC

Manufacturer: Belimo

$0.00

Qty:

Spring Return Damper Actuator, LF Series, 9-11/16 in. Length, 3-27/64 in. Width, 3-5/32 in. Height, 24 VAC/VDC Volts, AMP: 4 - 20 mA, 2.5W Running, 1W Holding Watts, 5 VA Rating, Shaft Type: 1/2 to 1-3/64 in. Round or 13/32 to 1-3/64 in. Square, 90 in-lbs Torque Rating, Stroke Degree: 0 to 95, Signal Type: Proportional, Maximum Temperature: -22 to 122F Ambient

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	9-11/16 in.
Width	3-27/64 in.
Height	3-5/32 in.
AMP	4 - 20 mA
Maximum Temperature	-22 to 122F Ambient
Torque Rating	90 in-lbs
VA Rating	5
Volts	24 VAC/VDC
Watts	2.5W Running, 1W Holding
