N++ 13205 3/4" CXC BALL VALVE 600WOG

BMI 13205 Lead Free Forged Brass Ball Valve, 3/4 in., Solder (Copper)

Manufacturer: BMI

$0.00

Qty:

Ball Valve, Forged Brass, End Connection 1: Solder (Copper), Pressure - Maximum: 600 psi WOG (Non-Shock), Specifications - FM Approved: Yes, Specifications - UL Listed: Yes, End Connection 2: Solder (Copper), Specifications - ASTM: ASTM C-46500, Valve Operator: Handle, PTFE Valve Seat, Valve Size: 3/4 in., Steel Handle, FPM O-Ring Valve Seal, Forged Brass Valve Stem, PTFE Valve Packing, Maximum Temperature: -20 to 300F, Specifications - ANSI: ANSI B16.18, ANSI Z21.15/CGA 9.1 and CAN/CGA 3.16, Specifications - ASME: ASME B16.33, ASME B16.44, Lead Law Compliant: Yes, Specifications - NSF: NSF 61, Specifications - NSF Certified: Yes, Forged Brass Ball Valve Trim

Products specifications

products.specs.attributename	products.specs.attributevalue
Material	Forged Brass
End Connection 1	Solder (Copper)
End Connection 2	Solder (Copper)
Handle Material	Steel
Lead Law Compliant	Yes
Maximum Temperature	-20 to 300F
Pressure - Maximum	600 psi WOG (Non-Shock)
Specifications - ANSI	ANSI B16.18, ANSI Z21.15/CGA 9.1 and CAN/CGA 3.16
Specifications - ASME	ASME B16.33, ASME B16.44
Specifications - ASTM	ASTM C-46500
Specifications - FM Approved	Yes
Specifications - NSF	NSF 61
Specifications - NSF Certified	Yes
Specifications - UL Listed	Yes
Valve Operator	Handle
Valve Packing Material	PTFE
Valve Seal Material	FPM O-Ring
Valve Seat Material	PTFE
Valve Size	3/4 in.
Valve Stem Material	Forged Brass
Valve Trim Material	Forged Brass Ball
