BOS083210

Boshart 0832-10 Forged Brass 2-Piece Gas Valve, 1 in., FNPT x FPT

Manufacturer: Boshart

$0.00

Qty:

Gas Valve, Forged Brass, End Connection 1: FNPT, End Connection 2: FPT, Maximum Temperature: 125F, Pressure - Maximum: 250 psi, Recommended Valve Application: Gas, Specifications - UL Listed: Yes, Valve Body Style: 2-Piece, PTFE Valve Seat, Valve Size: 1 in., Specifications - ANSI: ANSI Z21.15 and CGA 9.1, Specifications - ASME: ASME B16.44 and CGA/CR91-002, 0.79 in. Port Diameter

Products specifications

products.specs.attributename	products.specs.attributevalue
Material	Forged Brass
End Connection 1	FNPT
End Connection 2	FPT
Maximum Temperature	125F
Port Diameter	0.79 in.
Pressure - Maximum	250 psi
Recommended Valve Application	Gas
Specifications - ANSI	ANSI Z21.15 and CGA 9.1
Specifications - ASME	ASME B16.44 and CGA/CR91-002
Specifications - UL Listed	Yes
Valve Body Style	2-Piece
Valve Seat Material	PTFE
Valve Size	1 in.
