EBH69WA4

69W Rugged Steel Case Pressure Switch, 5 psi Close Cut-In, 65 psi Open Cut-In

$0.00

Qty:

Pressure Switch, Model: 69W, 3-19/32 in. Length, 2-1/4 in. Width, 2-9/32 in. Height, Rugged Steel Case and Cover, Specifications - UL Listed: Yes, 5 psi Close Cut-In, 65 psi Open Cut-In, 15 - 30 psi Differential Pressure Rating, Horsepower: 1.5 hp at 1 PH - 120V, 2 hp at 1 PH - 240V, 3 hp at 3 PH - 240V

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	3-19/32 in.
Width	2-1/4 in.
Height	2-9/32 in.
Material	Rugged Steel Case and Cover
Horsepower	1.5 hp at 1 PH - 120V, 2 hp at 1 PH - 240V, 3 hp at 3 PH - 240V
Pressure Rating	5 psi Close Cut-In, 65 psi Open Cut-In, 15 - 30 psi Differential
Specifications - UL Listed	Yes
