V3410 155 CHR 3/4 HSW 8.0K QR

Victaulic K8.0 V3410 Quick Response Horizontal Sidewall Sprinkler 155 Degree F / 68 Degree C, Chrome

Manufacturer: Victaulic

$0.00

Qty:

FireLock Standard Spray Sprinkler Head, Model: V3410, 2-15/16 in. Height, Die-Cast Brass 65-30 Frame, Colour/Finish Name: Chrome-Plated, End Connection 1: MNPT, Fitting Size 1: 3/4 in., 8 K-Factor, 155F Maximum - Temperature, Pressure - Maximum: 175 psi, Specifications - UL Listed: Yes, 7 psi Working Pressure, 100% at 500 psi Factory Hydrostatic Test, 100F Ambient Temperature Rating, Deflector: UNS C22000 Material Specification, All Hazard, V34 Recessed and Open End Wrench, 17/32 in. Orifice Size, Horizontal Sidewall Deflector Type, Quick Response Type, 3mm Red Bulb Element, Glass with Glycerin Solution Bulb Material, Bronze Deflector Material, Global Origin

Products specifications

products.specs.attributename	products.specs.attributevalue
Wrench	V34 Recessed and Open End
Working Pressure	7 psi
Response Type	Quick
Material Specification	Deflector: UNS C22000
Factory Hydrostatic Test	100% at 500 psi
Maximum Temperature	155F
K-Factor	8
Hazard	All
Deflector Material	Bronze
Element	3mm Red Bulb
Deflector Type	Horizontal Sidewall
Ambient Temperature Rating	100F
Bulb Material	Glass with Glycerin Solution
Orifice Size	17/32 in.
Colour/Finish Name	Chrome-Plated
Specifications - UL Listed	Yes
Height	2-15/16 in.
Material	Die-Cast Brass 65-30 Frame
Pressure - Maximum	175 psi
End Connection 1	MNPT
Fitting Size 1	3/4 in.
