V3421 155 CHR 3/4 UPRT 14K ECOH STD

Victaulic K14.0 V3425 Extended Coverage Ordinary Hazard Standard Response Upright 155 Degree F / 68 Degree C, Chrome

Manufacturer: Victaulic

$0.00

Qty:

FireLock Extended Coverage Sprinkler Head, Model: V3425, 2-1/2 in. Height, Die-Cast Brass 65-30 Frame, Colour/Finish Name: Chrome-Plated, End Connection 1: MNPT, Fitting Size 1: 3/4 in., 14 K-Factor, 155F Maximum - Temperature, Pressure - Maximum: 175 psi, Specifications - UL Listed: Yes, 7.8 psi Working Pressure, 100% at 500 psi Factory Hydrostatic Test, 100F Ambient Temperature Rating, Deflector: UNS C51000 Material Specification, Ordinary Hazard, V34 Recessed and Open End Wrench, 3/4 in. Orifice Size, Upright Deflector Type, 1-15/16 in. Diameter Deflector Size, Up to 400 sq-ft Coverage Area, Standard Response Type, 3mm Red Bulb Element, Glass with Glycerin Solution Bulb Material, Bronze Deflector Material, Global Origin

Products specifications

products.specs.attributename	products.specs.attributevalue
Coverage Area	Up to 400 sq-ft
Wrench	V34 Recessed and Open End
Working Pressure	7.8 psi
Response Type	Standard
Material Specification	Deflector: UNS C51000
Factory Hydrostatic Test	100% at 500 psi
Maximum Temperature	155F
K-Factor	14
Hazard	Ordinary
Deflector Material	Bronze
Element	3mm Red Bulb
Deflector Type	Upright
Deflector Size	1-15/16 in. Diameter
Ambient Temperature Rating	100F
Bulb Material	Glass with Glycerin Solution
Orifice Size	3/4 in.
Colour/Finish Name	Chrome-Plated
Specifications - UL Listed	Yes
Height	2-1/2 in.
Material	Die-Cast Brass 65-30 Frame
Pressure - Maximum	175 psi
End Connection 1	MNPT
Fitting Size 1	3/4 in.
