C++ 59896145 UP15-42B5 1/2" SWT 115V

Grundfos UP 15-42 B5 Bronze Open System Small Stator Circulator Pump, 115V at 60Hz, 1 PH, 1/25 hp

Manufacturer: Grundfos

$0.00

Qty:

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	4-11/16 in.
Height	5 po
Material	Bronze
AMP	0.74A
Bearing Material	Aluminum Oxide Ceramic
Capacitance	10mfd/180V
End Connection 1	Sweat
Fitting Size 1	1/2 in.
Frequency Rating	60Hz
Horsepower	1/25 hp
Impeller Material	PES Composite
Maximum Feet of Head	42 dm
Maximum Temperature	176F Liquid, 104F Ambient
Motor Type	Inline
Phase	1 PH
Port-To-Port Length	5 in.
Power Rating	85W
Pressure - Maximum	145 psi
Pump Body Material	Bronze
Pump Motor Type	2-Pole Canned Rotor
Shaft Material	Aluminum Oxide Ceramic
Specifications - NSF	NSF 61
Specifications - NSF Certified	Yes
Specifications - UL Listed	Yes
VAC at 60 Hz	115V
