92603112 ALPHA HWR 15-29 SF/ T 115V 9H

Grundfos 92603112 ALPHA Series 15-29F 115V 1/2 hp Cast Iron Circulator Pump
Manufacturer: Grundfos
$0.00
ALPHA HWR is a high-efficiency circulator fitted with a stainless steel housing. It is designed for circulating domestic hot water in systems with a dedicated return line.Circulator comes with built-in temperature control, eliminating the need for an external aquastat.With the use of it's integrated sensor that estimates temperature, the ALPHA HWR helps reduce complexity during installation as an external temperature sensor is no longer needed.The AUTOADAPT setting offers a simplified commissioning process, removing the need to decide what set point to use.With FLOWSENSE, the ALPHA HWR can solve a number of challenges commonly found in domestic hot water recirculation systems. Through the use of flow limits, the ALPHA HWR reduces the risk of flow accelerated corrosion in the recirculation pipes by reducing the flow velocities while still providing enough flow to kick on the most common tankless boilers
Products specifications
products.specs.attributename products.specs.attributevalue
Product Type Circulator Pumps
AMP 0.41
End Connection Flanged
Flow Rate 7.26 gpm
Height 7-1/2 in.
Length 6-49/100 in.
Material Stainless Steel
Maximum Feet of Head 9.51 ft
Maximum Temperature 203
Minimum Temperature 36
Pressure - Maximum 174.92 psi
Pump Phase Single Phase
Specifications - NSF Certified No
Specifications - UL Listed Yes
Style Name ALPHA HWR 15-29 SF/T
Volts 115V
Watts 21 W
Weight 6.00 lb
Origin Denmark
Phase Single Phase
