GRU96416381

Grundfos CRN 32-1-1 A-G-G-E-HQQE 96416381 16 bar Stainless Steel Single Stage Centrifugal Pump, 5 hp, 36 cu-m/hr, 3461 RPM, 2-1/2 in. Flanged

Manufacturer: Grundfos

$0.00

Qty:

Single Stage Centrifugal Pump, Model: CRN 32-1-1 A-G-G-E-HQQE, 12-5/8 in. Length, Material: Stainless Steel, End Connection 1: Flanged, Fitting Size 1: 2-1/2 in., Flow Rate: 36 cu-m/hr, Horsepower: 5 hp, Impeller: AISI 316 Stainless steel, Maximum Temperature: 120C, Pressure - Maximum: 16 bar, Pump Body Material: AISI 316 LN Stainless Steel, RPM: 3461 RPM, 60Hz Frequency Rating, 2.2kW Power Rating, Flange Size: 182TC, Liquid Temperature Range: -40 to 120C, Pressure Stage: 150 lbs., Primary Shaft Seal: HQQE, Pump Version: A, Code for Rubber: E, Material Code: G

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	12-5/8 in.
Material	Stainless Steel
End Connection 1	Flanged
Fitting Size 1	2-1/2 in.
Frequency Rating	60Hz
Horsepower	5 hp
Impeller	AISI 316 Stainless steel
Material Code	G
Maximum Temperature	120C
Power Rating	2.2kW
Pressure - Maximum	16 bar
Pump Body Material	AISI 316 LN Stainless Steel
RPM	3461 RPM
