GRU98126823

Grundfos MAGNA1 32-100 F Cast Iron Single Head Circulator Pump with Integrated Variable Speed Drive, 115V, 208 - 230V at 60Hz, 1 PH, 1/6 hp

Manufacturer: Grundfos

$0.00

Qty:

Single Head Circulator Pump with Integrated Variable Speed Drive, Model: MAGNA1 32-100 F, 6.9 in. Length, 7.92 in. Width, Material: Cast Iron, AMP: 1.61A, End Connection 1: Threaded Flanged, Flow Rate: 313 gpm, Horsepower: 1/6 hp, 100 dm Maximum Head, Maximum Temperature: 230F, Phase: 1 PH, Pressure - Maximum: 175 psi, 4-Pole Permanent Magnet Pump Motor, Specifications - NSF: NSF 372, Specifications - NSF Certified: Yes, 115V, 208 - 230V at 60 Hz, 60Hz Frequency Rating, Stainless Steel Shaft, Aluminum Oxide/Carbon Bearing, Type 2, IPX4D (EN 60529) Enclosure, 8.62 - 178W Power Rating, PES ComposImpeller, Environmental Conditions: 95% RH, Port-To-Port Length: 165mm

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	6.9 in.
Width	7.92 in.
Material	Cast Iron
AMP	1.61A
Bearing Material	Aluminum Oxide/Carbon
Enclosure	Type 2, IPX4D (EN 60529)
End Connection 1	Threaded Flanged
Environmental Conditions	95% RH
Frequency Rating	60Hz
Horsepower	1/6 hp
Impeller Material	PES Composite
Maximum Feet of Head	100 dm
Maximum Temperature	230F
Phase	1 PH
Port-To-Port Length	165mm
Power Rating	8.62 - 178W
Pressure - Maximum	175 psi
Pump Motor Type	4-Pole Permanent Magnet
Shaft Material	Stainless Steel
Specifications - NSF	NSF 372
Specifications - NSF Certified	Yes
VAC at 60 Hz	115V, 208 - 230V
