20128 1"X100' BLUE STRIPE PEX-ATUBE
Heatlink 20128 Blue PureLink Plus 1 in. x 100 ft. UV Stabilized PEX-a Tubing
This PureLink tubing is made of high molecular cross-linked polyethylene and comes in blue. It measures 21-3/5 inside diameter x 1-1/8 inches outside diameter and has 0.03032 USG/ft fluid volume. The 1 inch tubing has a minimum 6 inch bend radius, a 100 feet length, a 0.125 inch wall thickness, working pressure of 160 PSI, an operating temperature of 200 degrees Fahrenheit and weighs 16.97 lb. It is IAPMO listed and meets the ANSI 372, ANSI 263, ASTM F-876, ASTM F-877, ASTM F-1807, ASTM F-1960, ASTM F-2023, ASTM F-2080, ASTM F-2098, ASTM F-2159, ASTM F-2657, ASTM E-84, AWWA C-904, CSA B137.5, NSF 14, NSF 61, NSF 372 standards.
