V800C1052 COMBINATION GAS CONTROL

Honeywell Home V800C1052/U Gas Valve, 3/4 x 3/4 in. NPT with 1/2 in. NPT Side
Manufacturer: Honeywell Home
$0.00
Gas Valve, 4-1/16 in. Width, 4-3/4 in. Height, 335000 btu/hr at 1 in. WC, 34000 btu/hr Minimum, 425000 btu/hr Maximum BTU, Inlet/Outlet: 3/4 x 3/4 in. NPT with 1/2 in. NPT Side, 24 VAC Volts, Temperature Rating: 32 - 175F, 1/2 psi Pressure Rating, Fuel Type: Natural Gas, Body Pattern: Straight-Through, Multi-Tapped with 1/2 in. Right and Left Outlets Plugged, Ignition Type: Standing Pilot, Pressure Regulator Setpoint: 0.9 in. WC Non-Adjustable Step Setting, 3.5 in. WC Full Rate, 1/8 in. NPT with Plug Outlet Pressure Tapping, Electrical Connection: Combination Screw and 1/4 in. Male Quick Connects, Mounting Type: 0 - 90 Degree in Any Direction from the Upright Position of the Gas Control Knob, Including Vertically, Step Pressure Regulator, Opening Characteristics: Step Opening, 60Hz Frequency Rating, Pilot Gas Outlet: 1/4 in. OD Tubing, Depth: 3-3/16 in.
Products specifications
products.specs.attributename products.specs.attributevalue
Width 4-1/16 in.
Height 4-3/4 in.
Body Pattern Straight-Through, Multi-Tapped with 1/2 in. Right and Left Outlets Plugged
BTU 335000 btu/hr at 1 in. WC, 34000 btu/hr Minimum, 425000 btu/hr Maximum
Depth 3-3/16 in.
Electrical Connection Combination Screw and 1/4 in. Male Quick Connects
Frequency Rating 60Hz
Fuel Type Natural Gas
Ignition Type Standing Pilot
Inlet/Outlet 3/4 x 3/4 in. NPT with 1/2 in. NPT Side
Motor Type 0 - 90 Degree in Any Direction from the Upright Position of the Gas Control Knob, Including Vertically
Opening Characteristic Step Opening
Pilot Gas Outlet 1/4 in. OD Tubing
Pressure Rating 1/2 psi
Pressure Regulator Step
Pressure Regulator Setpoint 0.9 in. WC Non-Adjustable Step Setting, 3.5 in. WC Full Rate
Pressure Tapping 1/8 in. NPT with Plug Outlet
Temperature Rating 32 - 175F
Volts 24 VAC
