JOCP170AA118C

Johnson Controls Penn P170AA-118C Steel Single Low Pressure Control, 24A at 120 VAC, 18.7A at 208 VAC, 475 psi, SPST

Manufacturer: Johnson Controls

$0.00

Qty:

Penn Single Low Pressure Control, P170 Series, 4 in. Width, 4-3/16 in. Height, Material: Steel, AMP: 24A at 120 VAC, 18.7A at 208 VAC, 17A at 240 VAC Standard, 24A at 208/240 VAC Hermetic Compressor, Depth: 2-1/16 in., Specifications - NEMA: NEMA 1, 120 - 240 VAC Volts, 100 - 400 psi, 35 - 200 psi Differential, 200 psi Close, 150 psi Open, 475 psi Working Pressure Pressure Rating, SPST Configuration, Pilot Duty Rating: 125 VA at 120 - 600 VAC, 57.5 VA at 120 - 300 VDC, Switch Action: Open on Low Pressure, Pressure Connection: 1/4 in. External Flare Connector, Horsepower: 2 hp at 120 VAC, 3 hp at 208/240 VAC

Products specifications

products.specs.attributename	products.specs.attributevalue
Width	4 in.
Height	4-3/16 in.
Material	Steel
AMP	24A at 120 VAC, 18.7A at 208 VAC, 17A at 240 VAC Standard, 24A at 208/240 VAC Hermetic Compressor
Configuration	SPST
Depth	2-1/16 in.
Horsepower	2 hp at 120 VAC, 3 hp at 208/240 VAC
Pilot Duty Rating	125 VA at 120 - 600 VAC, 57.5 VA at 120 - 300 VDC
Pressure Connection	1/4 in. External Flare Connector
Pressure Rating	100 - 400 psi, 35 - 200 psi Differential, 200 psi Close, 150 psi Open, 475 psi Working Pressure
Specifications - NEMA	NEMA 1
Switch Action	Open on Low Pressure
Volts	120 - 240 VAC
