JOCP32AF2C

Johnson Controls Penn P32AF-2C Cold Rolled Steel Differential Sensitive Pressure Switch, 5.8A at 120 VAC, 3.3A at 208 VAC, 0.05 - 5 in. WC, SPDT

Manufacturer: Johnson Controls

$0.00

Qty:

Penn Differential Sensitive Pressure Switch, P32 Series, 3.24 in. Width, 5.56 in. Height, Material: Cold Rolled Steel Case and Housing, AMP: 5.8A at 120 VAC, 3.3A at 208 VAC, 2.9A at 240 VAC, Colour/Finish Name: Zinc-Plated, Depth: 2.22 in., Specifications - NEMA: NEMA 1, 120 - 240 VAC Volts, 0.05 - 5 in. WC Setting Range, 1 psi Maximum Over-Pressure, 0.025 in. WC Sensitivity at Minimum Setpoint Pressure Rating, SPDT Configuration, Pilot Duty Rating: 125 VA, 24 VAC, 360 VA, 120 to 277 VAC, Pressure Connection: 1/8 in. Internal NPT Inside, 1/2 in. NPSM Outside for Mounting for High Pressure Connectors, 1/8 in. Internal NPT for Low Pressure Connectors, Horsepower: 1/4 hp

Products specifications

products.specs.attributename	products.specs.attributevalue
Width	3.24 in.
Height	5.56 in.
Material	Cold Rolled Steel Case and Housing
AMP	5.8A at 120 VAC, 3.3A at 208 VAC, 2.9A at 240 VAC
Colour/Finish Name	Zinc-Plated
Configuration	SPDT
Depth	2.22 in.
Horsepower	1/4 hp
Pilot Duty Rating	125 VA, 24 VAC, 360 VA, 120 to 277 VAC
Pressure Connection	1/8 in. Internal NPT Inside, 1/2 in. NPSM Outside for Mounting for High Pressure Connectors, 1/8 in. Internal NPT for Low Pressure Connectors
Pressure Rating	0.05 - 5 in. WC Setting Range, 1 psi Maximum Over-Pressure, 0.025 in. WC Sensitivity at Minimum Setpoint
Specifications - NEMA	NEMA 1
Volts	120 - 240 VAC
