KIT5122EL3

Kitz 5122EL Ductile Iron Locking Lever Handle Wafer Style Butterfly Valve, 3 in., Flanged

Manufacturer: Kitz

$0.00

Qty:

Kitz Butterfly Valve, DJ Series, Model: 5122EL, Ductile Iron, End Connection 1: Flanged, Pressure - Maximum: 200 psi, End Connection 2: Flanged, Specifications - ASTM: ASTM A-536 Grade 65-45-12, ASTM A-276, Valve Operator: Locking Lever Handle, NBR/EPDM Valve Seat, Valve Size: 3 in., Dimension: 6 in. Actual Outside Diameter, 7.09 in. Centre to Top of the Handle, 410 Stainless Steel Valve Stem, Aluminum Bronze Valve Disc, Specifications - MSS: MSS SP-67, SP-25, Material Specification: C95400, Pressure Class: 125/150#, Valve Body Style: Wafer

Products specifications

products.specs.attributename	products.specs.attributevalue
Material	Ductile Iron
Dimension	6 in. Actual Outside Diameter, 7.09 in. Centre to Top of the Handle
End Connection 1	Flanged
End Connection 2	Flanged
Material Specification	C95400
Pressure - Maximum	200 psi
Pressure Class	125/150#
Specifications - MSS	MSS SP-67, SP-25
Valve Body Style	Wafer
Valve Disc Material	Aluminum Bronze
Valve Operator	Locking Lever Handle
Valve Seat Material	NBR/EPDM
Valve Size	3 in.
Valve Stem Material	410 Stainless Steel
