RAW237K

237 1/2"CC SLD BZ #125 CHECK VALVE

Red & White 002-40002 1/2 in. 125 psi Solder Cast Bronze Swing Check Valve
Manufacturer: Red & White
$0.00
This Y-pattern swing check valve is made of cast bronze and has a 3/4 inch Solder Joint end connection. It has a maximum pressure of 200 WOG, a working pressure of 0.86 MPa and a 125# pressure class. The lead law compliant valve has a 2-5/8 inches length and meets ASME B16.18, ASTM B-62 C-83600 and MSS SP-80 standards.
Products specifications
products.specs.attributename products.specs.attributevalue
End Connection Solder (Copper) x Solder (Copper)
End Connection 1 Solder (Copper)
End Connection 2 Solder (Copper)
Lead Law Compliant Yes
Length 2-5/8 in.
Material Cast Bronze
Pressure - Maximum 200 psi WOG
Pressure Class 125#
Specifications - ASME ASME B16.18
Specifications - ASTM ASTM B-62 C-83600
Specifications - MSS MSS SP-80
Style Name Model: 237A
Valve Body Style Y-Pattern
Valve Disc Material Brass;Bronze
Valve Size 1/2 in.
Product Type Check Valves
