TACMA417070502

DuraDrive 2-Position Spring Return Actuator, MA41-707X Series, 4 in. Width, 10-1/2 in. Height, 120 VAC Volts, AMP: 500 mA, 7A Resistive at 250 VAC, Running: 4.2W at 50Hz, 3.6W at 60Hz, Holding: 2W at 50Hz, 1.2W at 60Hz Watts, 10.7 at 50Hz, 5.6 at 60Hz VA Rating, 60 - 250 in-lbs Torque Rating, Timing: Less Than 80 sec. Powered, Less Than 40 sec. Spring Return at 70 Degree, Number of Auxiliary Switch: 2, Depth: 3-1/2 in., Control Signal: On/Off SPDT or Triacs, Electrical Connection: 3 ft. Appliance Cable, 1/2 in. Conduit, Humidity Range: 5 - 95% RH Non-Condensing, Temperature Rating: -22 to 140F Operating, NEMA 1 (IEC IP30), NEMA 2 (IEC IP54) Enclosure
