WATLF009NRS3

Watts LF009-NRS 3" Cast Iron Reduced Pressure Zone Assembly, Nrs Shutoff, Lever Handles

Manufacturer: Watts

$0.00

Qty:

Reduced Pressure Zone Assembly, LF009 Series, Model: LF009-NRS, 34-1/4 in. Length, 17-1/2 in. Width, 17-1/4 in. Height, Material: Epoxy Coated Cast Iron, End Connection 1: Flanged, End Connection 2: Flanged, Lead Law Compliant: Yes, Maximum Temperature: 140F, Pressure - Maximum: 175 psi, Recommended Valve Application: Water, Specifications - ASSE Standards: ASSE 1013, Specifications - AWWA: AWWA C-511, Specifications - CSA Certified: CSA B64.4, Specifications - UL Listed: Yes, Stainless Steel Valve Seat, Valve Size: 3 in., Non-Rising Valve Stem, Gate Valve, 7.5 ft/sec Capacity

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	34-1/4 in.
Width	17-1/2 in.
Height	17-1/4 po
Material	Epoxy Coated Cast Iron
Capacity	7.5 ft/sec
End Connection 1	Flanged
End Connection 2	Flanged
Lead Law Compliant	Yes
Maximum Temperature	140F
Pressure - Maximum	175 psi
Recommended Valve Application	Water
Specifications - ASSE Standards	ASSE 1013
Specifications - AWWA	AWWA C-511
Specifications - CSA Certified	CSA B64.4
Specifications - UL Listed	Yes
Valve Seat Material	Stainless Steel
Valve Size	3 in.
Valve Stem	Non-Rising
Valve Type	Gate
