N++ CGA-8-PIDN ELEC IGN BOILER NG 245MBH

Weil Mclain CGA-8-PIDN Cast Iron Natural Gas Boiler, 4.4 gal, 245 MBH Input, 204000 btu/hr Heat

Manufacturer: Weil McLain

$0.00

Qty:

Boiler, Gold Series 2 Series, 34 in. Length, 23-1/4 in. Width, 64-7/8 in. Height, Material: Cast Iron, 82.7% AFUE, 204000 btu/hr BTU Heat Rating, 4.4 gal Capacity, Fuel Type: Natural Gas, Electronic Ignition System, Input: 245 MBH, 1-1/2 in. Return Pipe, Supply Pipe Connection Size: 1-1/2 in., 3/4 in. Gas, Pressure - Maximum: 50 psi Working, 30 psi Relief Valve, Vent Size: 7 in., Net AHRI Rating: 177 MBH

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	34 in.
Width	23-1/4 in.
Height	64-7/8 in.
Material	Cast Iron
AFUE	82.7%
BTU Heat Rating	204000 btu/hr
Capacity	4.4 gal
Fuel Type	Natural Gas
Ignition System	Electronic
Input	245 MBH
Net AHRI Rating	177 MBH
Pressure - Maximum	50 psi Working, 30 psi Relief Valve
Return Pipe Connection	1-1/2 in.
Supply Pipe Connection Size	1-1/2 in., 3/4 in. Gas
Vent Size	7 in.
