SMV532 1/4FNPT X 1/4MNPT MINI BALL VALVE

Winters SMV532 Forged Brass Tee Handle Mini Ball Valve, 1/4 x 1/4 in., MNPT x FNPT

Manufacturer: Winters

$0.00

Qty:

Mini Ball Valve, 1.535 in. Length, Forged Brass, End Connection 1: MNPT, End Connection 2: FNPT, -9 to 212F Maximum - Temperature, Pressure - Maximum: 400 psi, Valve Operator: Tee Handle, Valve Size: 1/4 x 1/4 in., Steel, Plated, Plastic Covered Handle, Specifications - ASME: ASME B1.20.1, Dimension: 1.24 in. Inlet Centre to Top of Valve, 1.614 in. Handle Length, Stainless Steel Ball Valve Trim

Products specifications

products.specs.attributename	products.specs.attributevalue
Length	1.535 in.
Material	Forged Brass
Dimension	1.24 in. Inlet Centre to Top of Valve, 1.614 in. Handle Length
End Connection 1	MNPT
End Connection 2	FNPT
Handle Material	Steel, Plated, Plastic Covered
Maximum Temperature	-9 to 212F
Pressure - Maximum	400 psi
Specifications - ASME	ASME B1.20.1
Valve Operator	Tee Handle
Valve Size	1/4 x 1/4 in.
Valve Trim Material	Stainless Steel Ball
