MA41-7070 ACT. ON/OFF 120 VAC 60 (LB.IN)

DuraDrive 2-Position Spring Return Manual Override Damper Actuator, 4 in. Width, 10-1/2 in. Height, Material: Rugged Die-Cast Housing, 120 VAC Volts, 4.2W at 50Hz, 3.6W at 60Hz Running, 2W at 50Hz, 1.2W at 60Hz Holding Watts, 10.7 at 50Hz, 5.6 at 60Hz VA Rating, 60 in-lbs Minimum, 250 in-lbs Maximum Stall Torque Rating, Timing: Less Than 80 sec. Powered, Less Than 40 sec. Spring Return, 50/60Hz Frequency Rating, Depth: 3-1/2 in., Control Signal: On/Off SPST Contacts or Triacs (500 mA), Motor Type: Brush, -22 to 140F Ambient Ambient Temperature, Humidity Range: 5 - 95% RH Non-Condensing, Electrical Connection: 3 ft. Long Appliance Cable, 1/2 in. Conduit Connectors, Enclosure Rating: NEMA 2, IP54
